输出电路 | TL | HT/R | F/E/C | 最大转速 | 6000r/min |
电源电压 | 5V±0.25 | 9-30V | 9-30V | 径向负荷 | 50N |
消耗电流 | 200mA | 200mA | 200mA | 轴向负荷 | 30N |
响应频率 | 100KHZ | 100KHZ | 100KHZ | 重量 | 300g |
允许负载 | 20mA | 20mA | 30mA | 防护等级 | IP65 |
信号高电平 | 2.5V | 70%*Vcc R : ≥2.5V | 70%*Vcc | 工作温度 | -20℃ ....+85℃ |
信号低电平 | <0.5V | <0.5V | <1V | 储存温度 | -25℃ ....+100℃ |
上升时间 | 100ns | 100ns | 1us | 抗冲击 | 1000m/s2 , 6ms |
下降时间 | 100ns | 100ns | 1us | 抗震动 | 100m/s2, 10....200Hz |
脉冲数 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 启动力矩 | 3×10-3 N.m Max |
输出电路 | TL | HT/R | F/E/C | 最大转速 | 6000r/min |
电源电压 | 5V±0.25 | 9-30V | 9-30V | 径向负荷 | 50N |
消耗电流 | 200mA | 200mA | 200mA | 轴向负荷 | 30N |
响应频率 | 100KHZ | 100KHZ | 100KHZ | 重量 | 300g |
允许负载 | 20mA | 20mA | 30mA | 防护等级 | IP65 |
信号高电平 | 2.5V | 70%*Vcc R : ≥2.5V | 70%*Vcc | 工作温度 | -20℃ ....+85℃ |
信号低电平 | <0.5V | <0.5V | <1V | 储存温度 | -25℃ ....+100℃ |
上升时间 | 100ns | 100ns | 1us | 抗冲击 | 1000m/s2 , 6ms |
下降时间 | 100ns | 100ns | 1us | 抗震动 | 100m/s2, 10....200Hz |
脉冲数 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 1~1024, 1200,1250,1500,1600,1800,2000 2048,2500,3000,3200,3600,4000,4096,4500 5000,6000,7200,8000,8192,10000 | 启动力矩 | 3×10-3 N.m Max |
